TECHNICAL SPECIFICATIONS
SolarRO SW 60
Seawater Reverse Osmosis System
Product water flow rate
2.4 m³/h
Clean water recovery rate
35 %
Energy consumption
13.8 kWh
Energy per m³ of clean water
5.8 kWh/m³
Make Clean Water with Solar. Cut Costs. Build Resilience.
- Fast to Deploy. Easy to Operate.
- Flexible Power Options.
- Built to Last.
Technical Specifications
| Product water flow rate* | 2.4 m³/h |
| Product water quality* | TDS < 140mg/L, ph 6.5 |
| Raw water feed flow rate | 6.9 m³/h |
| Recovery rate* | 35 % |
| Minimum salt rejection | 99.5 % |
| Brine flow rate* | 4.5 m³/h |
| Brine quality* | TDS 52900 mg/L |
| System pressure | 52 – 57 bar |
| High-pressure pump | Super duplex, axial piston pump (15 kW) |
| HPP motor | 11 kW |
| Raw water feed pump** | 1,5 kW, bronze/AISI 316L |
| Pressure vessels | 2 x 8080 |
| RO Membranes | 4 x 8040 SW30HRLE or equivalent |
| Cartridge pre-filtration** | PP 30”, 5-element, 25 and 3 micron |
| Controller | Variable frequency solar drive (15 kW) |
| Specific energy*** | 5.8 kWh/m³ |
| Solar PV input power** | 21 kWp (minimum) |
| DC power supply requirement (solar PV) | 600 – 800 VDC |
| AC power supply requirement (grid) | 380 – 480 VAC / 50 – 60 Hz |
* Test Conditions: Seawater TDS 36 000 mg/l, pH 8, T 25°C, system pressure 53 bar ** Raw water pump model and characteristics subject to change depending on site-specific requirements *** Raw water feed pump included Specifications and system design are subject to change without prior notice. |
Operating Conditions
| Raw water source | Seawater / high saline groundwater |
| Raw water TDS range | 20000 – 40000 mg/L |
| Raw water temperature range | 5 – 45 °C |
| Air temperature range | 0 – 45 °C |
| Raw water feed pressure range | 2 – 5 bar |
Standard features
- Patented ANVS® pressure control
- Non-corrosive materials: Super Duplex, PVC-U
- UV-disinfection
- Integrated CIP (clean in place) system
- Dry run and over-pressure protection
- Product water quality indicator (TDS)
Customizable features
- Remote Monitoring
- Multi-Media filtration
- Specific substance removal filtration
- Antiscalant dosing
- Containerized system (20ft)
- Integrated clean water dispensing system
- Post-mineralization
